Oil cup size: 90mm diameter

Steel plate/sheet size: 100*250mm

Maximum printing range: R80mm

Maximum glue head pressure: 1870N at 6bar

Gas consumption: 228litre/min (approx.)

1.The products are placed in the positioning fixture in order

2.laser machine for laser engraving

3.three-color servo motor drive printing

4.printing is completed, people hand material

Declaration: Machine production rate is affected by the following conditions:

Printing requirements, ink change conditions, feed/feed control, rubber head push speed, rubber head hardness, production equipment laser machine engraving speed, printing effect and production control.
